20-500TPD High Performance Oil Machinery to Make Rice Bran Oil in America and India with PLC

Specifications

Oil Machinery to Make rice bran oil
1,low energy consumption
2,high oil yield and purity
3,save solvent
4,high performance

20-500TPD High Performance Oil Machinery to Make rice bran oil in America and India with PLC

Cathy wu

Mobile : 15938721580

Skype : cathy.wu666

Alibaba: cn1500376114

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="600">

Simple Craft Flow Chart

Pretreatment and Press process:

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="300">

Cleaning and separating----steaming----cooking----pressing----filter----crude oil

Each step purpose:

A, Cleaning and separating: Remove the broken rice and other impurities, that can guarantee the oil yield

B, Steaming: In order to soften the crude fibre and conglomerate the protein,break the cell wall,small oil drip can gather into the big oil drip, so that the oi can be easily out.

Condition: rotate speed: 40 temperature:80~100°C time:10min moisture:25~30%

C, Cooking: lower the moisture in the rice bran, so that oil can be easily out,

Condition: stir constantly.temperature:125°C,time:20~30min,moisture lower to:5~7%.

D, Press condition: temperature:80~90°Ctime:3~5min

E, Filter condition: temperature: 70°C

Refining process:

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="300">

Crude oil----degumming----deacidification----decoloring----filter----deodorizing----fourth grade oil

Crude oil----degumming----deacidification----decoloring----filter----deodorizing----dewaxing----degrease----first grade oil

Four grades oil in China Standard

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="350">

Introduction of Rice Oil Making Craft in Detail

Cleaning and Separating:

This process mainly to remove the impurities like iron,sand,broken rice and others. If the impurities exist in the rice bran, it will affect the machines operation. And make the crude oil impure,then largely affect the refining process.

The cleaning method mainly includes screen and magnetic separation.

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="600">

Steaming:

This process namely soften the rice bran,making the bran cooked.as the rice bran is low oil content and low moisture content, so it has to through steaming to adjust its moisture and temperature to a suitable level, that can increase the rice bran elastic-plastic. break the cell wall and oil easily out when pressing.

Cooking:

This process has the same purpose with steaming, aiming to make the oil out easily, the difference is just lower the moisture to 5~7%,to much water content will affect the oil outing.

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="500">

Pressing:

This is the oil out process, the cooked rice bran will be sent to screw oil press machine through the screw conveyor. After pressing, we can get the crude rice bran oil.

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="600">

Filter:

Filter the crude oil with canvas or double layer cloth in the Plate-fram filter, control the temperature to 70°C,then the crude oil will be sent to the refining process.

Refining Plant:

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="400">

Phosphoric acid alkali clay vacuum

↓ ↓ ↓ ↓

Crude oil---- degumming ----deacidification ----decoloring ----deodorizing ----fourth grade oil

↓ ↓ ↓ ↓

Oil sediment soapstock Clay residue waste gas

Introduction of the whole process:

A,First send the crude oil into the mix reactor with certain quantity water and acid, after well blended send into the centrifugal separator and then separate the oil sediment.

B,Second send into another mix reactor, adding certain concentration alkali and well neutralization reaction. Separate the soapstock through the centrifugal separator.

C,Now wash the crude oil with light alkali and water, washing out the residual soapstock.

D,Third send the oil into the bleaching tower,well blended with certain quantity clay, under the certain temperature,time,vacuum condition, the clay absorb the colorful substance and other impurities. Then separating the waste clay through the centrifugal separator.

E,At last send the oil into deodorization tower,under the certain temperature and vacuum condition, deodorizing the oil through steam stripping. Then get the fourth grade oil.

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="600">

rice bran oil in America and India with PLC" style="display: block; margin-left: auto; margin-right: auto;" ori-width="600" ori-height="600">

Our machines advantages:

1,some of our technology adopts Germany standard, and some equipment parts are imported.

2,our stainless steel and carbon steel are all purchased directly from the steel factory.our professional engineer will detect every time.so we can guarantee the quality.

3,all of our welding technicians have the employment certificates.they are good at it.

4,we provide installation and professional training.

5,we supply the best service to our customer,if there is any technology problem,we will transfer it to our customer.

Professional suggestion:

Kindly please inform us your required daily capacity, quantity, raw material, covering space and related data,

so that we can provide you professional equipment information and design proper oil production line for you. we will suggest economical and reasonable production line for you.

Shandong Leader Machinery Co.,ltd. oil press machine is composed of feeder, gearbox, pressing cage, screw shaft and machine stand etc.The Fully-automatic oil machine also have oil filter and heating system. Pretreatments of Oilseeds in Oil Production Line utilize the screw shaft that is setup with different styles of screws and rotates when machine is running to push the material into chamber. Then the oil is separated out through the extrusion of pressing worm and pressing ring.
20-500TPD High Performance Oil Machinery to Make rice bran oil in America and India with PLC Main parts of chamber through the processing of high-temperature tempering and low temperature quenching;Cake thickness can be adjusted once the machinery stop running;20-500TPD High Performance Oil Machinery to Make rice bran oil in America and India with PLC Final oil is high quality, good smell, and high yield rate.

If you have any demand about microwave drying equipment and edible oil refining equipment, pls feel free contact us any time.
Email:sales21@ldfoodmachine.com
Whatsapp:+86 13064099546
Skype:leaderfoodmachine21
Contact:Mandy

NOTE:We can specially design the machine according to your production's features.
