Home>Products>Biodiesel Oil Production Line>fully automatic grain mill

fully automatic grain mill
- Jinan, China (Mainland)
- Biodiesel Oil Production Line
- IS0/CE
Biodiesel Oil Production Line
- 1 Set/Sets flour mill machinery
- Biodiesel Oil Production Line
- Contact with us
- paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
- 30 Set/Sets per Month flour mill machinery
Product Details
Condition: | New | Place of Origin: | Jinan, China (Mainland) | Brand Name: | LD |
Model Number: | LF-300 | Production Capacity: | 100% | Voltage: | 220V/380V/440V |
Power(W): | according to flour mill machinery | Weight: | according to flour mill machinery | Dimension(L*W*H): | 14*7.5*6m |
Certification: | IS0/CE | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Name: | flour mill machinery | Raw material: | Wheat, Maize, Corn | Final products: | Super Fine Flour |
Capacity: | 5-300 tons/24 hours | Application: | Grain milling | Color: | According to your requirement |
After sales service: | Mobile Phone 24hours Open | Material: | Cast Iron\carbon Steel\stainless Steel | Quality: | European Standard |
Type: | Grain Processing Equipment |
Product Description
This treatment technology of Biodiesel Oil Production Line is newly developed by our company Shandong Leader Machinery Co.,ltd., which can meet high quality standards of biodiesel and have many advantages such as fast reaction speed, high conversion rate, vitriol not required to be catalyst, sulphur controlled below 10ppm, small corrosivity to equipment, zero waste water discharge and others. The research of this technology fully automatic grain mill changed the record of using heterogeneous catalyst in old technologies, breaking the history of only having national standard biodiesel but no European standard biodiesel.Our company Shandong Leader Machinery Co.,ltd. regards "quality is life"as our enterprise spirit. Our products have already passed relevant International Quality Management System Certifications. Our products are also exported to European Union. We adopt highly abrasive materials and advanced processing technique of fully automatic grain mill, making the devices have long service life and wear-proof performance. We have won a great reputation at home and abroad.
low price wheat flour mill
product description
1. The clean part of wheat flour mill machinery:
Includes beating, screening, destoner, magnetic separator and dampening. Different capacity machine line has different number of beat, screen and destoner.
1.1 Beating: through the beat function of the wheat scourer, brusher to remove dust sand small seed, bacterial count and insect seed.
1.11 wheat scourer
Technical Parameter:
Technical Parameter | Drum Diameter(mm) | Drum Length(mm) |
Speed (mm) |
Capacity (T/H) |
Power (KW) |
Weight (KG) |
L*W*H (mm) |
FDMWA30*60 | Φ300 | 600 | 650-780 | â¤12 | 7.5-15 | 760 | 1220*600*1615 |
FDMWA45*80 | Φ450 | 800 | 437-520 | 12-25 | 15-22 | 980 | 1460*800*1876 |
1.2 Screening: to remove large and small impurities in the wheat seed by make the wheat go through vibrating sieve and aspiration sieve.
1.3 Destoner: mainly remove stone in the wheat to prevent them milled into the flour and also protect the roller on the milling process.
Technical Parameter:
Technical Parameter |
Screen Width (cm) |
Capacity (T/H) |
Air Pressure (Pa) |
Air Volume (m3/h) |
Swing (mm) |
Screen Leaning Angle(°) |
Power (KW) |
Swing (time/min) |
Weight (KG) |
Size (mm) |
TQSF43 | 43 | 1-1.5 | 3000 | 4-5 | 5-9 | 2*0.25 | 960 | 215 | 1270*700*1600 | |
TQSF50 | 50 | 2-4 | 4000 | 4-5 | 5-9 | 2*0.25 | 960 | 230 | 1420*780*1800 | |
TQSF60 | 60 | 3-5 | 4500 | 4-5 | 5-9 | 2*0.25 | 960 | 280 | 1450*876*1800 | |
TQSF80 | 80 | 5-7 | 6000 | 4-5 | 5-9 | 2*0.25 | 960 | 340 | 1450*1046*1800 | |
TQSF100 | 100 | 7-9 | 8000 | 4-5 | 5-9 | 2*0.25 | 960 | 400 | 1500*1246*1900 | |
TQSF125 | 125 | 9-11 | 10200 | 4-5 | 5-9 | 2*0.25 | 960 | 500 | 1470*1496*1900 | |
TQSFB125 | 125 | 15-18 | 12000 | 4-5 | 5-9 | 2*0.55 | 960 | 650 | 1649*1714*2083 | |
TQSF150 | 150 | 11-14 | 12000 | 4-5 | 5-9 | 2*0.25 | 960 | 600 | 1580*1746*1900 | |
TQSFB150 | 150 | 18-20 | 15000 | 4-5 | 5-9 | 2*0.55 | 960 | 760 | 1649*1964*2083 | |
TQSF175 | 175 | 14-18 | 15000 | 4-5 | 5-9 | 2*0.25 | 960 | 750 | 1470*1990*1900 | |
TQSF200 | 200 | 16-20 | 17000 | 4-5 | 5-9 | 2*0.25 | 960 | 1000 | 1470*2292*1900 | |
TQSF250 | 250 | 20-22 | 204000 | 4-5 | 5-9 | 2*0.25 | 960 | 1050 | 1470*2835*1900 |
1.4 Magnetic separator: remove metal material in the wheat to keep the roller safe and also avoid flour explosion accident of spark caused by the impact of the metal impurities and the machine.
1.5 Dampening: dampening the wheat bran before mill to ensure the branâs integrity during the milling processing, avoid the bran going into the flour to keep flour quality.
2. The flour milling part of wheat flour mill machinery:
Include different number of mill and sifter to mill the wheat and separate the flour and bran.
(1) Mill: mill the wheat to break the integrity by the roller moving
(2) Sifter: to separate the flour and bran, also separate large size and small size to ensure flour quality.
3. Packing part of wheat flour mill machinery:
The packing part can be manual also can be auto, this can be designed according to requirement and machine capacity.
4. Parameters of wheat flour mill machinery:
Model | LF-10 | LF-20 | LF-30 | LF-40 |
LF-50 |
LF-60 |
LF-80 |
LF-100 |
Capacity (Ton/day) |
10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
Main machine dimension (L*W*H)(M) |
14*7.5*6 | 16*7.5*6.5 | 18*7.5*7 | 22*7.5*7 | 24*7.5*7 | 30*8*12 | 33*8*12 | 33*10*12 |
Total power (KW) |
56 | 86 | 94 | 131 | 144 | 223 | 327 | 340 |
Our Factory
Henan LD Group was founded in 1976, after nearly 40 years of development and growth, has become a well-known Chinese grain and oil machinery manufacturing enterprises with import and export rights, in 2002 passed the ISO9001 quality management system certification, National Food Processing Equipment Engineering Technology Research Center, the National agro-processing technology and equipment research and development sub-centers and the provincial post-doctoral research base development platform.







Shipments

FAQ
Q1. What flour mill capacity can you provide?
A: We produce 5-1000 tons/24 hours, which means processing 5-1000 tons wheat/corn per day.
Q2. Can wheat, corn and rice produced on the same production line?
A: Wheat, corn and rice normally can not producing on the same production line. Because the wheat grain and corn grain has different physical property and some parts need different equipments. Even the same equipments, the model is different.
Q3. What factors need to be considered to design and install a whole set of flour milling equipments?
A: Flour milling design need to consider the wheat/corn you are using, local geographical conditions, climate, power type, customer's request etc. So flour milling machine is different for customer from different country.
Q4. How is the quality of your product ?
Our product are manufactured strictly according to national and international standard,and we
take strict test before delivery.
Q5.Guaranteed
If productsâquality is not consistent with the description as we described or the promise before
you place order,we promise 100% refund
More information ,pls contact as follows:
Biodiesel Oil Production Line Totally getting rid of sulfur as catalyst and fully overcoming the problem of equipment corrosion caused by sulfur.fully automatic grain mill Products meet the sulfur content standards since we stopped using sulfur as catalyst.Because we don’t adopt reaction of methyl alcohol and free fatty acid, so no water exists in methyl alcohol, which reduces fully automatic grain mill equipment investment.Shandong Leader Machinery Co.,ltd. By reason of not using mineral acid,emission loads of acid water and acid slag have greatly decreased, relatively reducing environmental pollution; Shandong Leader Machinery Co.,ltd. Some glycerin can be recycled and utilized continuously for several times, which saves production costs. Biodiesel Oil Production Line Products and raw materials exchange heat continuously for several times, realizing the cyclic utilization of thermal energy and significantly saving production costs of Biodiesel Oil Production Line.Independently researched and developed turbulent flow type tubular reactor fully automatic grain mill can realize continuous reaction at low temperature and product quality can be controlled on-line at any time, which thoroughly solves the instability problem of products generated by kettle type reaction, getting standard products of unified quality.
If you have any demand about microwave drying equipment and edible oil refining equipment, pls feel free contact us any time.
Email:sales21@ldfoodmachine.com
Whatsapp:+86 13064099546
Skype:leaderfoodmachine21
Contact:Mandy
NOTE:We can specially design the machine according to your production's features.
